panel
The Panel
Mühlbauer four-blade-blade propeller with deice


Side uten callsign

Click on picture to the left for a footage from the checkride



Specifications:

Norwegian registry
LN-ACP
Year / Serial
1979 P2100207
TTSN
2500
Engine
Continental TSIO-520P
1400 TBO
TSO 100
New engine from Firewall Forward, Denver, Colorado, USA 2002
  • new cylinders
  • new cam
  • new shaft
  • new bearings
  • new hoses
  • new turbo
  • Riley Intercooler

Propeller
4 blade Mühlbauer with  electric deice
TTSN 100
Boots
Wing and elevator boots
Hot plate
Not approved for flight into known icing
Avionics
Audiopanel
Garmin GMA 340
Nav/Com/GS
Garmin GNS 430 with terrain
Nav/Com
King KX-155
DME
ARC 400
ADF
King KR-87
Indicator
GI-106A
Transponder - mode S
Garmin GTX330
Enc. Altimeter
KEA130
Engine monitor
JPI 700
GPS
Garmin GNS 430
Wx radar
King RDR-160 Color
WX radar Indicator
King RDR-130 mono
Autopilot
ARC-400B with altitude hold and glideslope
Exterior
Overall pearl white with yellow and navy blue striping, New 2001 by Fesek.
Interior
Antrasit leather new 1998 by Beechcraft.
Miscellanous
Rosen Sun Visors
Gear mirror
Electric standby horizon
Separate Intercom for pax with isolate function and music input
Engine preheat Reiff TurboXPi
Powertow EX40
Max. Altitude
23.000 ft
Cruise speed
165-180 kts
Fuel flow
70 ltr/h
Seats
5
Usable  fuel
89 USG/336 ltr
Max load full fuel
395 kg
Range
800 Nm
